EKKO Lithium Stand-up Rider Forklift | 4000lb Cap | 216" Lift Ht | EK18RF-LI

Stand-Up Efficiency: Lift 4000 lb to 216" in Narrow-Aisle Environments Lithium Rider Forklift

Overview

The EKKO EK18RF-LI is a lithium-powered stand-up rider forklift designed for high-cycle warehouse environments where speed, visibility, and maneuverability are critical. The stand-up configuration allows operators to enter and exit the vehicle quickly at every stop ideal for operations with frequent short-distance moves and multi-drop picking routes.

Benefits

• Speed up multi-stop operations stand-up design lets operators mount and dismount in seconds, dramatically reducing time wasted at each stop compared to seated forklifts.
• Lift and position loads precisely 4000 lb capacity and 216" lift height cover the full range of warehouse racking configurations.
• Work all shift without charging delays lithium-ion battery supports full-shift operation and opportunity charging during breaks with no maintenance required.
• Improve operator visibility elevated standing position provides a clear, unobstructed sightline to loads and surrounding personnel for safer operation.
• Navigate tight aisles with ease compact rear-wheel steering turns on a dime, enabling efficient operation in narrow-aisle layouts.
• Invest with confidence backed by a 3-Year Limited Warranty and EKKO's North American parts and service network.

Features

• Load Capacity 4000 lb
• Raised Height 216" (18ft)
• Side Shift
• Adjustable Forks 9.4-35.6"
• Fork Length 45.3€œ
• Hydraulic Steering
• Curtis Instrument Controller
• German AC Drive Motor
• Battery 48V/350Ah Lithium
• Solid Cushion Load Tires
• Polyeurathane Drive Tires
• Ergonomic Handle and Controls
• Steel Construction
• Robotic Welding
• Charger 440V three phase

Specifications

Manufacturer Warranty

This EKKO unit is covered by the EKKO 3-Year Limited Warranty: three (3) years on the frame, forks and mast; one (1) year on the transmission/gearbox, traction and steering motors, controllers and charger; one (1) year on lead-acid batteries and chargers (lithium batteries carry up to five (5) years on select models); and thirty (30) days on wear items such as tires, bulbs, lights, rubber parts and seals. LPG and diesel models: frame, forks and mast for 3 years or 6,000 hours and the engine for 2 years or 4,000 hours, whichever comes first. Coverage begins when the unit is purchased from the authorized dealer, is non-transferable, applies to the original purchaser under normal operating conditions, and excludes labor unless pre-approved by EKKO, normal wear, abuse, improper maintenance or unauthorized modification.

To make a warranty claim, contact Prime Supply Global at support@primesupplyglobal.com or +1 (978) 981-4630 with your order number, model, and photos or video of the issue. We coordinate the claim with the manufacturer on your behalf. Full details on our Warranty page.
