Product Description

EKKO Order Picker 2200lb. Cap., 196" Lift - EOP70

Pick Orders Faster at Heights Up to 196" Ergonomic, Lead-Acid-Powered Order Picker

Overview

The EKKO EOP70 is an electric order picker engineered for high-frequency order fulfillment in distribution centers, warehouses, and retail stockrooms. Designed to elevate the operator along with the load, it allows efficient picking at heights that are impossible from the ground dramatically increasing throughput and reducing walking time.

Benefits

  • Double your pick rates operator platform rises with the load up to 196", eliminating time spent repositioning ladders or carts.
  • Reduce picker fatigue ergonomic controls and a stable operator platform let your team work comfortably across long shifts without strain.
  • Maximize floor space utilization compact footprint and tight turning radius allow operation in narrow aisles and high-density storage layouts.
  • Lower labor costs faster, more efficient picking means fewer worker-hours per order, improving your cost-per-pick metrics.
  • Invest with confidence backed by a 3-Year Limited Warranty with dedicated EKKO parts and service support across North America.

Features

  • Load Capacity 2200 lb
  • Raised Height 196" (16.33 ft.)
  • Adjustable Forks
  • Auxiliary Fork
  • Triple Mast
  • Curtis Instrument Controller
  • EPS (Electronic Power Steering)
  • German AC Drive Motor
  • Battery 24V/280Ah
  • 24V/50A
  • Polyurethane Wheels
  • Ergonomic Handle and Controls
  • Steel Construction
  • Robotic Welding
  • Charger Included
  • BatteryIncluded

Specifications

Model

EOP70

Power unit

Electric

Operation

Stand on

Rated loading capacity

Q (lbs)

2200

Load centre

c (Inch)

19.68

Between fork backrest & front wheel

x (Inch)

7.56

Wheelbase

y (Inch)

53.46

Serviceweightwithbattery

lbs

6600

Wheels type

PU

Driving wheel size

Φ×w(Inch)　

Φ9.84×5

Bearing wheel size

Φ×w(Inch)　

Φ5.9×3.23

Wheels, number front/rear (x = driven)

1，/2

Track width

b11 (Inch)

37.8

Lowered mast height

h1 (Inch)

93.11

Lifting height

h3 (Inch)

196"

Extended mast height

h4 (Inch)

285

Height of overhead guard(cabin)

h6 (Inch)

89.48

height of seat/stand-on platform

h7 (Inch)

10.67

Additional lift height

h9 (Inch)

30.71

total lift height

h10 (Inch)

227

Platform lifting height

h12 (Inch)

206.873

Lowered fork height

h13 (Inch)

1.97

Picking height

h15 Inch)

258.01

Overall length

l1 (Inch)

111.41

Body Length

l2 (Inch)

69.29

Overall width

b1/ b2 (Inch)

39.37/145.28

Fork Size

s/e/l (Inch)

1.37/3.93/42.13

Width of fork fixing frame

b3 (Inch)

35.83

outside fork width

b5 (Inch)

34.33

Min.Ground clearance

m2 (Inch)

1.97

Aisle width for pallets 39.37*47.24 crossways

Ast (Inch)

122.24

Aisle width for pallets 31.5*47.24 lengthways

Ast (Inch)

126.77

Turing Radius

Wa (Inch)

61.81

Travel speed,laden/unladen

(km/h)

8

Lifting speed, with/without load(cabin)

(mm/s)

n/a

Lifting speed, with/without load(Fork)

(mm/s)

n/a

Lowering speed, with/without load(cabin)

(mm/s)

n/a

Lowering speed, with/without load(Fork)

(mm/s)

n/a

Climbing ability, with/without load

(%)

3/6

Brake Type

Electromagnetic brake

Drive Motor

(kW)

3

Lift Motor

(kW)

6

Battey, DIN 43531/35/36 A,B,C,no

no

Battery voltage/rate capacity

(V/Ah)

24/280

Battery Weight（±5%）

(LBS)

n/a

Type of drive control

AC

Noise level

(dB(A))

‰¤75

Manufacturer Warranty

This EKKO unit is covered by the EKKO 3-Year Limited Warranty: three (3) years on the frame, forks and mast; one (1) year on the transmission/gearbox, traction and steering motors, controllers and charger; one (1) year on lead-acid batteries and chargers (lithium batteries carry up to five (5) years on select models); and thirty (30) days on wear items such as tires, bulbs, lights, rubber parts and seals. LPG and diesel models: frame, forks and mast for 3 years or 6,000 hours and the engine for 2 years or 4,000 hours, whichever comes first. Coverage begins when the unit is purchased from the authorized dealer, is non-transferable, applies to the original purchaser under normal operating conditions, and excludes labor unless pre-approved by EKKO, normal wear, abuse, improper maintenance or unauthorized modification.
